Vacuum brazing platform

Design & specifications: from prototyping to small-scale production

For privacy reasons YouTube needs your permission to be loaded. For more details, please see our Legal notice.
I Accept

Develop high quality components for your specific operating conditions thanks to SuperGrid Institute’s expertise and state of the art vacuum brazing platform.

We can assist you in the design and testing of vacuum-brazed products, from the specification stage to small-scale production.

Download the leaflet

Our fully configurable platform meets the highest standards of cleanliness for assembling and testing your products or for studying the fundamental physics of plasma.

This platform has been designed to minimise your products’ exposure to any potential pollutant during the testing or production phases.

Our 55 m² ISO 5 assembly facility has an integrated vacuum high-temperature furnace coupled with an automated cleaning process for components meaning the rate of particle contamination is very low.

State of art vacuum brazing platform
Our combined expertise in modelling, assembly under vacuum conditions and high voltage testing makes us the perfect partner whether you are looking to increase your product’s technology readiness level or carry out customised small-series production for vacuum circuit breakers, variable capacitors, material assemblies for aerospace, X-ray or electronic tubes, connectors and more.

For research institutes or laboratories

Studying plasma, optimising the process of brazing various metals and ceramics under vacuum conditions, and/or gaining a better understanding of physical phenomena require expensive equipment and a high level of expertise. SuperGrid Institute can relieve you of these aspects and provide a competitive solution for your needs.

For industry

Our combined expertise in modelling, assembly under vacuum conditions and high voltage testing makes us the perfect partner whether you are looking to increase your product’s technology readiness level or carry out customised small-series production for vacuum circuit breakers, variable capacitors, material assemblies for aerospace, X-ray or electronic tubes, connectors and more.

Available services

SuperGrid Institute supports you in your research and small series production with its vacuum brazing platform and consulting services.

  • Work with customers to write product specifications

  • Design parts (finite element method)

  • Characterise parts within their context

  • Make recommendations to increasing products’ TRL

  • Produce small series of metal / ceramic parts that require brazing under vacuum conditions

This list is not exhaustive. Please contact us to express your needs so we can offer you a personalised service.

Reconfigurable vacuum test platform

Our modular platform offers the possibility of testing and validating electrical and mechanical equipment under vacuum conditions:

  • Vacuum arc and plasma diagnostics using a high speed camera (FASTCAM SA5) and UV-Vis spectroscopy.
  • Cold plasma behaviour.
  • Magnetron sputtering.

Specifications:

  • From 10-1 to 10-9 mbar.
  • Maximum dimensions for vacuum chamber: 0.3 m height x 0.45 m diameter.
  • Electrical feedthroughs up to 63 kAeff, 75 kV.
We use chemical cleaning to remove large and small particles that may contaminate individual parts. Parts are cleaned using a combination of acid, water and ultrasonic methods, ensuring that the surfaces are contamination-free and compatible with the most stringent vacuum requirements.

Automated cleaning process

We use chemical cleaning to remove large and small particles that may contaminate individual parts. Parts are cleaned using a combination of acid, water and ultrasonic methods, ensuring that the surfaces are contamination-free and compatible with the most stringent vacuum requirements.

Specifications:

  • Compatible with copper, stainless-steel, ceramics, etc.
  • Individual parts up to 35 kg.
  • Possibility of tailoring the cleaning process to our customers’ needs.

Clean room assembly

Our in-house prototyping platform contains all the essential tools necessary for performing individual to small-scale production in a particle-free environment.

Specifications:

  • 55 m² ISO 5 cleanroom for assembly.
  • Brazing temperature up to 1150 °C compatible with high-purity brazing alloys.
  • Operating pressure <10-6 mbar.
  • Assemblies up to Φ350 mm*1200 mm height and 250 kg.
  • Helium leak detection.
  • Special packing for storing parts.
Our in-house prototyping platform contains all the essential tools necessary for performing individual to small-scale production in a particle-free environment.
The brazing flux-free process produces very strong, void-free and corrosion resistant components. This is an essential requirement for parts that will be exposed to severe conditions, for example in the nuclear, medical, aerospace and defence industries.

Added value & consulting services

The brazing flux-free process produces very strong, void-free and corrosion resistant components.

This is an essential requirement for parts that will be exposed to severe conditions, for example in the nuclear, medical, aerospace and defence industries.
